Saudi Arabia 8-Lane Instant Coffee Powder Stick Packaging Solution

Customer Background

The customer’s coffee products included two different filling ranges:

Because 3-in-1 coffee contains coffee powder, sugar, and creamer, the filling system must handle different bulk densities and powder flow characteristics. For this reason, we configured a short auger dosing system with stirring, which is more suitable for coffee powder and mixed powder products.

Why the Customer Finally Chose Samfull After One Year of Comparison

This Saudi customer did not make a quick purchase decision. The whole project communication lasted for around one year. During this period, the customer compared multiple suppliers and evaluated machine configuration, production stability, cost, service response, and industry experience.

Finally, the customer selected Samfull for four main reasons.

1. Patient and Continuous Pre-Sales Support

For coffee packaging projects, customers often need to confirm many details before ordering, including filling weight, bag size, film width, dosing method, speed, sealing style, future cartoning connection, and factory layout.

During the long communication period, Samfull continuously provided technical support, machine configuration suggestions, and project explanations instead of simply pushing the customer to place an order. This helped the customer build confidence in the final solution.

2. Extensive Coffee Powder Packaging Experience

Coffee powder is not always an easy-flowing product. 3-in-1 coffee may contain creamer and sugar, while pure coffee powder may have different density and dust characteristics. These details directly affect dosing accuracy, sealing cleanliness, and finished bag quality.

Samfull has handled many coffee-related packaging projects, including:

• 3-in-1 coffee stick packs

• Pure coffee powder stick packs

• Instant coffee powder sachets

• Beverage powder stick packs

• Powder products with different flowability

• Stick pack counting and cartoning lines

This practical experience allowed us to recommend a more realistic configuration instead of using a generic powder packaging solution.

3. Professional Expertise in Multi-Lane Packaging Machines

The customer required an 8-lane back seal stick pack machine with stable high-speed production. Multi-lane machines are more complex than single-lane machines because film pulling, vertical sealing, horizontal sealing, dosing, cutting, and lane synchronization must work accurately at the same time.

For this project, the machine was designed for:

• 8-lane simultaneous production

• 200–240 packs per minute output

• Short auger dosing with stirring

• 35 mm × 175 mm stick pack size

• 640 mm total film width

• Serrated cutting

• Siemens control system

• English / Chinese touch screen interface

Our professional understanding of multi-lane packaging systems helped the customer reduce technical risk and choose a stable production solution.

4. High Cost-Performance Solution

The customer needed a machine that could meet real production requirements without unnecessary over-configuration. Samfull provided a practical and high cost-performance solution based on the customer’s current production stage.

The project focused on the core requirements:

• Stable coffee powder filling

• Reliable back sealing

• 8-lane production efficiency

• Safety protection

• Dust and static control

• Future upgrade possibility for counting and cartoning

This allowed the customer to invest in a professional coffee stick pack machine first, while keeping the possibility of upgrading to a complete coffee stick pack cartoning line later.

Machine Configuration Based on the Production Order

Layout drawing of  8-Lane Instant Coffee Powder Packaging Solution:

Coffee Powder Dosing Design

For this Saudi Arabia coffee project, the selected dosing system is a short auger with stirring device.

This design is suitable because coffee powder may have several production challenges:

Different Flowability Between 3-in-1 Coffee and Pure Coffee Powder

3-in-1 coffee contains multiple ingredients. Sugar, creamer, and coffee powder have different particle sizes and densities. If the feeding system is not stable, the filling weight may fluctuate.

Pure coffee powder usually has a smaller filling weight of 8–9 g, so dosing accuracy is also important.

Powder Bridging and Poor Feeding

Coffee powder and creamer-based powder may bridge inside the hopper. The stirring structure helps keep powder moving toward the auger screw, reducing empty filling and unstable dosing.

Dust Control During Multi-Lane Filling

An 8-lane machine fills multiple stick packs at the same time. If dust is not controlled, powder may enter the sealing area and affect sealing quality. For this reason, the project includes a dust removal device.

Output Capacity

The production order requires a speed of:

200–240 packs per minute

For an 8-lane machine, the average single-lane speed is:

25–30 packs per minute per lane

This output is suitable for medium and large coffee factories that need stable daily production. Compared with simply pursuing higher speed, this configuration gives better balance between speed, filling stability, sealing quality, and machine cost.

Bag Size and Packaging Format

The customer’s required stick pack size is:

35 mm width × 175 mm length

This slim stick pack format is widely used for instant coffee because it is convenient for:

• Single-cup coffee serving

• Retail box packing

• Hotel and office coffee supply

• Travel-size coffee packs

• Supermarket and convenience store sales

The machine uses back sealing and serrated cutting, without easy tear notch. This design keeps the stick pack simple, clean, and cost-effective.

Safety and Auxiliary Devices

The guard door interlock improves operator safety. When the safety door is opened, the machine can stop automatically.

The static elimination device helps improve film running stability, especially when using composite film in dry workshop environments.

The dust removal system is especially important for coffee powder because it helps reduce powder floating and improves the cleanliness of the sealing area.
